Back Connection Low Pressure Gauge
All stainless steel material, suitable for micro pressure measurement (pressure range from 0.25kPa to 60kPa) with the corrosive medium
Optional overpressure safety device
Description
Applications
- All stainless steel material, suitable for micro pressure measurement (pressure range from 0.25kPa to 60kPa) with the corrosive medium
- Optional overpressure safety device
Technical Parameters
|
Product name |
2.5inch-60mm Back connection low pressure gauge |
|
Model number |
YE-60D |
|
Diameter size |
(1.5")40mm; 2"(50mm); 2.5"(63mm); 3.5"(75mm); 4"(100mm); 4.5"(125mm);6"(150mm); 8"(200mm); 10"(250mm) etc. |
|
Case/cover |
Nickel-plated case |
|
Window |
General glass |
|
Connection |
Brass Bottom (back/back with clamp or flange etc.) |
|
Thread |
G/PT/NPT 1/8;1/4;1/2;M14x1.5;M20x1.5 ,ect |
|
Bourdon tube |
Bellows |
|
Movement |
Brass-nickel plated |
|
Dial plate |
aluminum |
|
Pressure range |
0.25kPa – 100kPa |
|
Accuracy |
2.5% |
|
Liquid filling |
/ |
|
Liquid |
/ |
How to order?
Pressure gauge model / Dial size / Scale range / Thread size / Mounting type / Optional extras required
Specifications and dimensions give in this leaflet represent the state of engineering at the time of printing.
