Black Steel Case Duplex Pressure Gauge
This gauge is mainly used for railway rolling stock as this can simultaneously perform pressure measurements of two spots by using the built-in two pressure receiving parts.
Description
This gauge is mainly used for railway rolling stock as this can simultaneously perform pressure measurements of two spots by using the built-in two pressure receiving parts.
|
Product name |
100mm Black steel case duplex pressure gauge |
|
Model number |
YCX-100AD |
|
Diameter size |
1.5"(40mm);2.5"(63mm); 3.5"(75mm); 4"(100mm); 4.5"(125mm)6"(150mm); |
|
Case/cover |
Black-steel case(Black / white color) |
|
Window |
glass |
|
Connection |
BRASS Bottom(back/back with clamp /bottom etc.) |
|
Thread |
G/PT/NPT 1/8;M10X1.customized |
|
Bourdon tube |
phosphor bronze |
|
Movement |
brass |
|
Dial plate |
Aluminum/plastic |
|
Pressure range |
20psi/1.4bar |
|
Accuracy |
1.6% |
|
Liquid filling |
No |
|
Liquid |
Dry |
Applications
Two matched internal systems, two matched bourdon tubes. Two pointer for displaying two different but related pressures on the same dial.
If you have another question, pls feel free to contact us
cooperation
Packing
