Bottom Connection SS Case Low Pressure Gauge
Weather protection:IP 54
Suitable for micro pressure measurement (pressure range from 0.25kPa to 60kPa) with the corrosive medium
Description
Weather protection:IP 54
Suitable for micro pressure measurement (pressure range from 0.25kPa to 60kPa) with the corrosive medium
Technical Parameters
|
Product name |
4inch-100mm bottom mounting Low pressure gauge |
|
Model number |
YE-100A |
|
Diameter size |
(1.5")40mm; 2"(50mm); 2.5"(63mm); 3.5"(75mm); 4"(100mm); 4.5"(125mm);6"(150mm); 8"(200mm); 10"(250mm) etc. |
|
Case/cover |
Stainless steel case |
|
Window |
General glass |
|
Connection |
Brass Bottom (back/back with clamp or flange etc.) |
|
Thread |
G/PT/NPT 1/8;1/4;1/2;M14x1.5;M20x1.5 ,ect |
|
Bourdon tube |
Bellows |
|
Movement |
brass |
|
Dial plate |
aluminum |
|
Pressure range |
0.25kPa – 100kPa |
|
Accuracy |
2.5%;1.0% |
|
Liquid filling |
/ |
|
Liquid |
/ |
Ranges
Range for Dial 2½", 3'': 1 kPa – 100kPa
Range for Dial 4'', 6'': 0.25kPa – 100kPa
temperature
Ambient: -22°C to +70°C
Medium: 100°C
cooperation
Packing
