Safety Patten Dial 63mm Solid Front Pressure Gauge

Safety pressure gauge with solid baffle wall designed in compliance with the requirements and test conditions of the DIN 16001 high-pressure standard High load cycle stability, even with dynamic pressure profiles

Send Inquiry

Description

Safety pressure gauge with solid baffle wall designed in compliance with the requirements and test conditions of the DIN 16001 high-pressure standard
High load cycle stability, even with dynamic pressure profiles
High indication accuracy of 1 %, optionally 0.6 %
Scale ranges from 0 ... 2,000 bar to 0 … 6,000 bar or from 0 ... 30,000 psi to 0 ... 85,000 psi
QR code on dial links to instrument-specific information

Technical Parameters

Product name	2.5inch-63mm Safety patten Solid front pressure gauge
Model number	YBF-60A
Diameter size	2.5"(63mm); 3.5"(75mm); 4"(100mm); 4.5"(125mm)6"(150mm);
Case/cover	Stainless steel case
Window	Safety glass
Connection	Stainless steel bottom (back/back with clamp /bottom etc.)
Thread	G/PT/NPT 1/8;1/4;1/2;M14x1.5;M20x1.5 ,ect
Bourdon tube	Stainless steel
Movement	Stainlesss steel
Dial plate	aluminum
Pressure range	-0.1Mpa~25Mpa
Accuracy	2.5%
Liquid filling	Yes
Liquid	Dry;Glycerin;Silicon oil
