Bottom Type All SS Electric Contact Pressure Gauge with Flange

Name: China Bottom Type All SS Electric Contact Pressure Gauge with Flange Manufacturers Suppliers Factory
Brand: Power
SKU: 249831672

Control and regulation of processes
Monitoring of plants and switching of circuits
For gaseous and liquid aggressive media that arenot highly viscous or crystallising, also in aggressiveenvironments

Send Inquiry

Description

Applications

■ Control and regulation of processes

■ Monitoring of plants and switching of circuits

■ For gaseous and liquid aggressive media that arenot highly viscous or crystallising, also in aggressiveenvironments

■ Chemical industry, petrochemical industry, power plants,mining, on-/offshore, environmental technology, machinebuilding and general plant construction

Technical Parameters

Product name	4inch-100mm Bottom type all SS electric contact pressure gauge with flange
Model number	YCX-100AD
Diameter size	2.5"(63mm); 3.5"(75mm); 4"(100mm); 6"(150mm);
Case/cover	Stainless steel case
Window	General glass
Connection	Stainless steel Bottom (back/back with clamp or flange etc.)
Thread	G/PT/NPT 1/8;1/4;1/2;M14x1.5;M20x1.5 ,ect
Bourdon tube	Stainless steel
Movement	Stainlesss steel
Dial plate	aluminum
Pressure range	-0.1Mpa~25Mpa
Accuracy	2.5%;1.6%'1.0%
Liquid filling	Yes
Liquid	Silicon oil

Outer Dia.	100, 150
Precision of Indication	1.60%
Precision of Setting	4%
Contact number	2
Max Operating Voltage	AC 380V or DC 220V
Max Current	1A
Power of Contact	30VA
Connection screw	M20X1.5 or promised special requirement
Glass	safety explosion-proof glass, normal glass
Scale pan	black words with white background
Protection grade	IP6
