Back Connection All SS Pressure Gauge
Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system;
Process industry: chemical/petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction.
Description
Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system;
Process industry: chemical/petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction.
Technical Parameters
|
Product name |
2.5inch-63mm Back connection all SS material thread type pressure gauge |
|
Model number |
YBF-60D |
|
Diameter size |
(1.5")40mm; 2"(50mm); 2.5"(63mm); 3.5"(75mm); 4"(100mm); 4.5"(125mm);6"(150mm); 8"(200mm); 10"(250mm) etc. |
|
Case/cover |
Stainless steel case |
|
Window |
General Glass/Tempered glass/Safety Glass |
|
Connection |
Stainless steel back(back/back with clamp or flange etc.) |
|
Thread |
G/PT/NPT 1/8;1/4;1/2;M14x1.5;M20x1.5 ,ect |
|
Bourdon tube |
Stainless steel 316 |
|
Movement |
Stainless steel |
|
Dial plate |
aluminum |
|
Pressure range |
-0.1~100mpa |
|
Accuracy |
1.0% |
|
Liquid filling |
yes |
|
Liquid |
Dry;Glycerin ; silicon oil |
Special Features
Excellent load-cycle stability and shock resistance
All stainless steel construction
Positive pressure ranges to 20,000 psi
cooperation
Packing
