Plastic Connector Medical Presure Gauge Back Connection
The gauge boasts a clear, easy-to-read interface, allowing medical professionals to swiftly assess pressure levels. The prominent display ensures quick and accurate readings, even in fast-paced medical scenarios.
Description
With Clear Visual Interface
The gauge boasts a clear, easy-to-read interface, allowing medical professionals to swiftly assess pressure levels. The prominent display ensures quick and accurate readings, even in fast-paced medical scenarios.
User-friendly Operation: With intuitive controls and a straightforward interface, the gauge is easy to operate even in high-stress medical situations. Medical practitioners can focus on patient care without struggling with complicated equipment.
Technical Parameters
|
Product name |
40mm 30ATM Plastic connector medical presure gauge back connection |
|
Model number |
Y-40D |
|
Diameter size |
1.5"(40mm);2"(50mm);2.5"(63mm); 3.5"(75mm); 4"(100mm); 4.5"(125mm)6"(150mm); |
|
Case/cover |
ABS case(Black / white color) |
|
Window |
PC glass |
|
Connection |
Plastix back (bottom) |
|
Thread |
G/PT/NPT 1/8;M10X1.customized |
|
Bourdon tube |
Phosphor bronze |
|
Movement |
brass |
|
Dial plate |
Aluminum/plastic |
|
Pressure range |
0-10ATM;0-30ATM'0-40ATM;0-55ATM |
|
Accuracy |
3.0% |
|
Liquid filling |
No |
|
Liquid |
Dry |
Applications
- Medical Inflation Device
- Inflation Device Kits
- Balloon Inflation Device
- Inflation Syringe
- Inflate and deflate dilation balloon
- Manual balloon catheter pump
If you have another question, pls feel free to contact us
